Wing Bend WB650

Specification

		WB650
V Width　　　mm		Equal to V30
Thickness mm	Mild Steel	1.6~6.0
	Stainless Steel	1.5~4.5
	Aluminum	2.0~6.0
Min. Angle		80°
Tool Length　　　mm		50,100,200
Tool Width　　　　mm		100
Tool Height　　　mm		100
Allowable Tonnage		1000kN/m
Holder	FEAT AFH Die Holder	×
	Reversible 1V Die Holder	×
	Special Die Rail	*Special Die Rail is required.

*When bending 6.0mm thick plate with WB650, please use R1.0 or less punches. If punch is more than R1.0, it may exceed allowable tonnage.

*Cracks may occur on bending part or outer R depending on materials.

*Please operate with direct mode if machine has NT control.

*Bending Elongation Value of Wing Bend is different from of V Bending slightly. Actual bending check is required. (Please refer to “Reference Bending Data” about reference data.)

*Black coating layer will peel off from outer shoulder radius first because of the characteristic.
