KIZU-NON SHEET
Spec & Code
Materials | Applicable Thickness t (mm) | Durability Test (for Reference) | |||||
---|---|---|---|---|---|---|---|
t (mm) |
Angle | V | R | No. of Bends | Condition | ||
SPCC | 0.5~1.6 | 1.6 | 90° | 12 | 0.8 | 370 | Partially thinner but still usable |
SUS | 0.5~1.5 | 1.0 | 90° | 8 | 0.8 | 200 | Continually Usable |
AL | 0.5~2.0 | 1.5 | 90° | 8 | 0.8 | 3000 | Continually Usable |
Type | Code (SK10) | Size and Unit |
---|---|---|
T-10 | 909950 | 100mm width x 10 meters x one piece |
*Data was obtained under the most severe condition with smaller shoulder radius of a 2V die.
*Number of bends was obtained without moving the position of the sheet. The sheet is 100mm wide, so by moving the position the sheet the life will be 4 to 5 times longer than the bending data in the table.
*The life can be increased further when using wider die with a bigger shoulder radius and also when the work edge is de-burred and free from dross.
*The texture pattern of the fabric can sometimes appear on the surface of softer material such Aluminium (52S). In such a case, increasing the V-width shoulder radius can eliminate this issue.
