• Adjustment/replacement became much easier.

Except grinding time, Conventional tooling took approx 6 min for assembly or adjustment. But NEXIII takes only approx 1 min.

• Handling is easy.

Anyone can use NEXIII easily without know-how.

• Height adjustment was improved.

Caliper is required for the height adjustment of conventional tooling, but NEXIII does not need it for the adjustment because it can be adjusted by looking the gap in height between guide and punch. It is easy and prevents mistakes.

• There is no need to polish tooling before processing.

Polishing conventional guides was required to reduce tool marking. This optional feature “Tool Mark-Less” eliminates this work.

Ｑ１. NEX3 with non-air-blow available?

Ａ１. Yes, it’s special-order tool.

Ｑ２. We have NEX spring pack. Can we use NEX on NEX3 tool?

Ａ２.Yes, you can use NEX on shaped tool, but forming tool is not applicable with NEX.

Ｑ３. Is there any interchangeability between NEX and NEX3?

Ａ３. NEX shaped punch body has an interchangeability with NEX3. But the round tool has no interchangeability.

Ｑ４ .Is NEX3 spring unit (spring and head ) repairable?

Ａ４. No! New set of NEX3 is required.

Ｑ５. Is the round punch body without pin available for NEX3?

Ａ５. No. Punch height changes during processing because NEX3 can not lock the round punch body without pin.

Ｑ６. We do not need ID marking. Can it be cheaper?

Ａ６. ID marking is standard spec. So the price does not change

Ｑ７. Is there any different color on spring cover available? We want to differentiate shaped and round tools.

Ａ７. Different color is not available. But you can write the characters on it with felt-tip-pen.

Ｑ８. Can we order “over-sized “ punch body ?

Ａ８. No. We can not supply bigger punch body than punch diameter.

Ｑ９. Are there any contouring tool, heavy-duty tool or high-speed marking tool with NEX3?

Ａ９. At the moment, only NEX spring pack type is available. But dedicated spring unit may be developed in future.
