Bending Products and Solutions

• AFH Tooling
• Modular Tooling
  • Punch
  • Die
  • Others
• EG-AR Tooling
  • Punch
  • Die
• Standard Tooling
  • Punch
  • Die
  • Others

• Value Added
  •
    Set up time reduced
    using heavy gauge 1V die
  •
    Lavor saving & set up time
    reduction for hemming work
  •
    Multi-purposed bending
    solution tool
  •
    Punch support for deep
    box products
• Scrach Prevention
  •
    Wing
    Bend
  •
    Polycarbonate
    Dies
  •
    Aluminum & stainless
    specific 2V dies
  •
    AX Tool
  •
    Polyurethane Dies
  •
    Urethane Sheet
  •
    Urethane Cap
  •
    Mark Protection Strip
  •
    Hard Chromium Plating
• Time Saving
  •
    AGRIP A/M
  •
    SGRIP
  •
    Hydraulic 1V Die Holder
  •
    Amada Modular
    Tooling System
  •
    AFH
    tool
  •
    Set up time reduced using
    heavy gauge 1V die
  •
    FEAT AFH Dieholder
  •
    Reversible 1V Die Holder
  •
    Wing Bend
  •
    Light-Weight Hemming
    Tool Ⅰ,Ⅱ
  •
    Light-Weight Hemming
    Tool Ⅲ
  •
    Super
    Multi II
  •
    fine offset
  •
    Qucik Change 2V Die
  •
    Reversible Acute 2V Dies
• Accuracy Support
  •
    Side Gauge for Sectionalized 1V Die
  •
    front table
    for 1V die
  •
    Side
    Gauge
  •
    Angle Variable Side Gaugeﾞ
• Long Life
  •
    ALP Burring punch No.Ⅲ
  •
    ALP Burring punch No.Ⅳ
  •
    ALP Sword Punch
  •
    AX Tool
  •
    AX1V Die
  •
    A.L.D. Tool
• Deep/Box bending
  •
    LBP Tool
  •
    Closing Punch
  •
    Punch Holder for Deep Bend
  •
    Narrow Distance Piece
  •
    Short Distance Piece
  •
    One-Touch Sub Holder
  •
    Sectionalized
    Distance Piece
• Management
  •
    M.T.S.298AFH
    For AFH Tools
  •
    M.T.S.298MD
    For Modular Tools
  •
    M.T.S.248ST
    For Standard Tools
  •
    M.T.S.486ST
    For Standard Tools
  •
    M.T.S.398MD
    For Modular Tool

Standard Punch

Image	Tool No.	Type	Angle	Height(mm)	Allow.Ton. (kN/m)
Standard Punch No.4	4	Standard	88°	67	1000
Standard Punch No.16	16	Standard	90°	67	1000
Standard Punch No.117	117	Standard	88°	67	200
Standard Punch No.116	116	Standard	90°	67	200
Burring Punch 0048	0048	Burring	88°	67	400
Burring Punch 0168	0168	Burring	90°	67	400
Burring Punch 0049	0049	Burring	88°	67	800
Burring Punch 0169	0169	Burring	90°	67	800
Gooseneck Punch 452	452	Gooseneck	88°	90	700
Gooseneck Punch 462	462	End of Sales	90°	90	700
Gooseneck Punch 453	453	Gooseneck	88°	90	500
Gooseneck Punch 463	463	End of Sales	90°	90	500
Gooseneck Punch 45	45	Gooseneck	88°	105	500
Gooseneck Punch 46	46	Gooseneck	90°	105	500
Gooseneck Punch 47	47	End of Sales	88°	120	500
Gooseneck Punch 48	48	End of Sales	90°	120	500
Sash Punch 200	200	Sash	88°	70	300
Sash Punch 201	201	Sash	90°	70	300
Sash Punch 20406	20406	End of Sales	84°	70	300
Sash Punch 202	202	Sash	88°	100	300
Sash Punch 203	203	Sash	90°	100	300
Sash Punch 20506	20506	End of Sales	84°	100	300
Straight Punch 109	109	Acute/Straight	88°	95	500
Straight Punch 108	108	Acute/Straight	90°	95	500
Acute Punch 1087	1087	ALP	30°	90	500
Burring Punch 00470	00470	ALP	88°	90	400
Burring Punch 4527	4527	ALP	88°	90	400
Hemming Punch 103	103	Hemming	30°	67	1000
Hemming Punch 210	210	Hemming	30°	104	1000
Acute Punch 8	8	Acute/Straight	45°	67	600
Acute Punch 215	215	Acute/Straight	45°	67	1000
Middle Height Standard Punch 5	5	Standard	88°	85	1000
Middle Height Standard Punch 6	6	End of Sales	90°	85	1000
Middle Height Punch Burring 0058	0058	Burring	88°	85	400
Middle Height Punch Burring 0068	0068	End of Sales	90°	85	400
Middle Height Punch Burring 0059	0059	Burring	88°	85	800
Middle Height Punch Burring 0069	0069	End of Sales	90°	85	800
Middle Height Punch Sash 010	010	Sash	88°	85	300
Middle Height Punch Sash 11	11	End of Sales	90°	85	300
Middle Height Punch Hemming 023	023	End of Sales	30°	85	1000
Radius Punch Kitchen Appliances 230	230	Radius		65	1000
Punches for Heavy Gauge 3	3	Radius		65	1000
Radius Rulers 17 R10	17	Radius		16	0
Radius Rulers 17 R15	17	Radius		20	0
Radius Rulers 17 R17.5	17	Radius		22	0
Radius Rulers 17 R20	17	Radius		24	0
Radius Rulers 17 R25	17	Radius		29	0
Radius Rulers 17 R30	17	Radius		34	0
Color radius 30	30	Radius		103	250
Punch Holder 15	15	Radius		67	1000
Gooseneck Punch Holder		End of Sales		120	300
Striking Plates 19	19	Hemming		20	1000
Coining Rulers 20	20	Hemming		28	1000
Flattening Punch 220	220	Hemming		65	1000
Hynged Type Punch		End of Sales		60	0
Multi-Radius Tip-Type Punch		Radius		60	0
